WP-18 Tongue & Groove 5-1/16"

This 5-1/16" - 1 WP-18 tongue & groove paneling measures 5.438" overall width and a thickness of .718", requiring a 5-11/16" wide blank of four-quarter lumber for milling on an industrial moulder. The traditional profile contains two 2-1/32" wide flat line segments divided by a 1/2" wide by 3/16" deep v-groove in the center with a 1/4" chamfer on both side edges. The groove dimensions are 7/16" wide by 9/32" tall. The tongue measures 3/8" wide by 17/64" tall with a .010" void in the joint area for expansion and contraction of the material during seasonal changes in relative humidity. When two pieces of milled lumber are joined together, they create a 1/2" v-groove between the merged boards.

Mirror Reflections provides the cut steel size on all their template & knife designs, this important information allows you to purchase the correct size width of knife steel before you start grinding procedures for production, this is just one more example of our enthusiasm for the overall success of your woodworking business.
