Crown Moulding 6-31/32"

This stylish crown moulding 6-31/32" measures 6.961" wide by 1.000" thickness. The classy profile is comprised of a 5/8" tall vertical line at the top, connected to a four tangent radius cyma recta, joined to a 17/32" wide beveled line with a 33/64" wide horizontal line at the bottom of the design. The spring angles are fixed at forty-five degrees, these specific back bevels set the installed height at 4-3/4" tall with a projection of 5-3/32" wide. Two high points in the detail were purposely positioned on the same plane, these specialized design features will assure excellent hold down conditions while milling, providing the moulder pressure shoe is parallel to the machine bed plates.

Architects, interior designers, lumber mills, and manufacturers have been utilizing our vast variety of creative designs for years, we trust you will find that special profile to enhance the architectural style of your client's home. If you have any questions or concerns about knife grinding procedures for any of our profiles, please contact us, we would be honored to assist you.

For knife quoting purposes use the calculator below, we have added only the important measurements, just determine the cutters you need. A brief detailed explanation on how to use the calculator is located here. Need some assistance with the dimensions? Print a copy of our fraction - decimal - millimeter chart, place it on the moulder to help operators save time and increase accuracy during machine setup.

Width = 6.961" / Depth of Cut = .757" (top knives).

Thickness = 1.000" / Depth of Cut = .579" (right blades) & .336" (left cutters).
