WP-2 Tongue & Groove 5-1/16" - 1

This 5-1/16" -1 WP-2 tongue & groove paneling measures 5.438" overall width and a thickness of .718", requiring a 5-11/16" wide blank of four-quarter lumber for milling on a commercial-grade molder. The long-established profile is composed of a 2-15/16" flat section in the center, attached to a 1/4" broad by 5/32" deep chamfer on the right. The opposite side of the pattern retains a traditional Pickwick design consisting of a 1-1/16" broad cove with beveled edges, joined to a 5/16" wide half-circle on each side. When two machined boards are joined together they create a 2-1/8" wide Pickwick pattern on one face of the merged boards, and a 1/2" by 5/32" deep v-groove on the opposite side of the profile, enabling you to choose either side for your specific application.

Architects, interior designers, contractors, lumber mills, cabinet shops, and molding manufacturers are utilizing our wide variety of molding designs. We trust you will find that particular profile to enhance the architectural style of your client's home or office. Be sure to download all our free Dxf files; see how easily the services we provide can increase productivity and reduce your manufacturing cost.
