Tongue & Groove 4-3/16"

This 4-3/16" beadboard tongue and groove measures 4.437" overall, with a face dimension of 4.188" wide, with a .750" thickness. The profile comprises two 7/64" radius half-round circles flanked by two fifty-five degree chamfers separated by 1-11/16" wide horizontal lines. When two pieces of milled lumber are joined together, they create a 13/32" wide vee channel with a 7/32" wide recessed by .020" bead in the center. There is also .016" of voided area in the joint for expansion and contraction of the wood during seasonal changes in relative humidity.

This cad generated dxf file contains three skillfully drafted template designs for making knives for this creative beadboard pattern. All our innovative profiles have a proven unbroken CNC (computer numerical control) tool path expediting the production process.
