Handrail 2-1/2" - 33
Handrail 2-1/2" - 33
This handrail measures 2.500" wide by 1.375" thick. The profile shape is rectangular, with 3/4" wide finger grasp areas that are 1/4" deep. The top is angled ten degrees on both sides with 1/8" radius edges. The bottom is milled to receive 1-1/4" wide balusters.
Moulding Knife Calculator
Grade of Steel
Subtotal
+ Custom Moulding Template
Total (Template + 2 Knives)
V2+RW
chrome coated 72rc face, best seller,
great tool life
$0.00
$0.00
$0.00
Black Nitride
black nitride case hardened
72rc, medium size runs
$0.00
$0.00
$0.00
Endurance
chrome and diamond coated, longest
tool life
$0.00
$0.00
$0.00
Note: If you’re experiencing trouble printing to Full Scale, Go to File,
Print Preview. Change the “Shrink to Fit” option to 100%
Right Cutter Head
Thickness: 2.375
Depth of Cut: 0.259
Left Cutter Head
Thickness: 2.375
Depth of Cut: 0.259
Top Cutter Head
Width: 2.500
Depth of Cut: 0.275
Bottom Cutter Head
Width: 2.500
Depth of Cut: 0.375
Grades of Steel
Price Per Cutter Head - Includes Template & Two Knives
V2+RW
chrome coated 72rc face, best seller
great tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$156.25
(Template not needed)
Black Nitride
black nitride case hardened 72rc
medium size runs
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$168.75
(Template not needed)
Endurance
chrome and diamond coated
longest tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$181.25
(Template not needed)
