Crown Moulding 6-3/8" - 13

This ovolo crown moulding 6-3/8" - 13 measures 6.364" wide by 1.250" thickness, necessitating the use of six quarter lumber for milling sprung (laying horizontally flat) out of six quarter lumber. The beautiful symmetrical profile is comprised of a 4-1/2" radius semicircular arc in the center, connected to a 1/2" by 3/4" tall perpendicular lines on both the top and bottom of the pattern. The spring angles are fixed at forty-five degrees, these explicit back bevels keep the inner portion of the profile parallel to the wall and ceiling when installed, they also set the positioned height at 4-1/2" tall with a projection of 4-1/2" wide. We suggest utilizing a felt lined pressure shoe to eliminate any unsightly burnish mark that may be left on the milled lumber caused by the steel hold down element on the moulder.

We offer a rather large group of alternative profiles with different widths, heights and projections, here are just a few of them you may want to review and consider for your current project, crown moulding 2.000" - 14, crown 2.500" - 13, crown 3.000" - 3, crown 3.250" - 23, crown 4.250" - 51, crown 5.250" - 11 and crown 8.500 - 11. From just an idea in one's mind, to reality in their home, our custom profiles reflect the creative style of your imagination, let us assist you in complementing your architectural decor with any of our attractive moulding designs.

For moulding knife quoting purposes click to open the calculator below, we supplied only the important measurements, just enter the appropriate dimension in the boxes provided. A brief detailed explanation on how to use the calculator is located here. If you would like some assistance with the dimensions feel free to print a copy of our fraction - decimal - millimeter chart, place it on the molder, or around the shop to help machine operators save time and increase accuracy during setup procedures.

Width = 6.375" / Depth of Cut = .898" (top knives).

Thickness = 1.250" / Depth of Cut = .442" (right blades) & .442" (left cutters).
