Crown 6" - 8

This ornate crown molding 6" - 8 measures 6.024" width by .812" thickness permitting the use of four quarter lumber for milling sprung (laying horizontally flat) on an industrial-grade molder. The decorative terminating profile contains a 15/32" tall vertical line joined to a 3/8" tall by 9/32" wide perpendicular notch on the top left. The notch merges with a three tangent radius s-shaped curvature forming the cyma recta in the center. The lower portion consists of a 23/64" tall by 7/32" wide right angle attached to a 13/32" convex arc with a 7/16" cove flanked by a small vertical & horizontal fillet on the design's bottom right side. The fixed spring angles are set at thirty-eight and fifty-two degrees; these particular back bevels keep the face side of the profile parallel to the wall and ceiling when installed; they also lock in the positioned height at 2-5/8" tall with a projection of 1-15/16" across the top.

All cad (computer-aided design) files contain important moulder setup and grinding information all designed to help you save time and money in the production process. Thanks for allowing us to help enhance a home's exquisite architectural details, one astonishingly gorgeous profile at a time.

For molding knife quoting purposes, click to open the calculator below; we supplied only the important measurements, enter the appropriate dimension in the boxes provided. A brief detailed explanation on how to use the calculator is located here. If you would like some assistance with the dimensions, print a copy of our fraction - decimal - millimeter chart, place it on the molder or around the shop to help machine operators save time and increase accuracy during setup procedures.

Width = 6.000" / Depth of Cut = .407" (top knives).

Thickness = .812" / Depth of Cut = .425" (right blades) & .834" (left cutters).
