Crown 4-1/4" - 9

Crown 4-1/4" - 9

Crown 4-1/4" - 9

This shaker-style 4-1/4" - 4 crown mould measures 4.000" width by .750" thickness, permitting the use of four-quarter lumber for milling sprung (laying horizontally flat) on an industrial moulder. The clean terminating mission profile can cut any size width within the parameters of the machinery used to mill the pattern. The detail contains a 5/16" tall vertical fillet on the top left and a 5/16" wide horizontal fillet on the design's bottom right side with a forty-five-degree flat angled line in the center. The set spring angles are at forty-five degrees; these dedicated back bevels keep the face side of the profile parallel to the wall and ceiling when installed; they also lock in the positioned height at 3" tall with a projection of 3" across the top.

Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%

Right Cutter Head
Thickness: 0.750
Depth of Cut: 0.603
Left Cutter Head
Thickness: 0.750
Depth of Cut: 0.603
Top Cutter Head
Width: 0.000
Depth of Cut: 0.000
Bottom Cutter Head
Width: 0.000
Depth of Cut: 0.000

Grades of Steel

Price Per Cutter Head - Includes Template & Two Knives

*If you want only to purchase the profile templates, review our price list
*All listed cutter head prices may not be necessary based on what you currently own
V2+RW
chrome coated 72rc face, best seller
great tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$130.50
$87.50
(Template not needed)
Not Needed
Not Needed
Total:
$218.00
Black Nitride
black nitride case hardened 72rc
medium size runs
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$137.50
$94.50
(Template not needed)
Not Needed
Not Needed
Total:
$232.00
Endurance
chrome and diamond coated
longest tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$144.50
$101.50
(Template not needed)
Not Needed
Not Needed
Total:
$246.00
To purchase this CAD generated, “template ready moulding dxf file” , please send $11.00 to PayPal.Me/MirrorReflections we will email you the precision drawing shortly after the payment is received.
