Door/Window Casing 4-1/2" - 36
Door/Window Casing 4-1/2" - 36
This designer 4-1/2" - 35 door/window casing measures 4.500" wide by 1.250" thickness, enabling the pattern to be machined from six-quarter lumber. The elegant profile is composed of a 3/4" broad horizontal line on the left, connected to a 3/16" wide by 3/16" deep dado and a 3/16" wide line that transitions into a 1-37/64" cavetto with a 1/8" vertical step, attached to a 1-7/8" flat segment with three small steps on the right side of the pattern. Get your creative juices flowing by adding one of our many backband profiles on the left side of the detail, here are a few you may want to review and consider,
backband .875" - 3 and
backband 1.500" - 3.
Moulding Knife Calculator
Grade of Steel
Subtotal
+ Custom Moulding Template
Total (Template + 2 Knives)
V2+RW
chrome coated 72rc face, best seller,
great tool life
$0.00
$0.00
$0.00
Black Nitride
black nitride case hardened
72rc, medium size runs
$0.00
$0.00
$0.00
Endurance
chrome and diamond coated, longest
tool life
$0.00
$0.00
$0.00
Note: If you’re experiencing trouble printing to Full Scale, Go to File,
Print Preview. Change the “Shrink to Fit” option to 100%
Right Cutter Head
Thickness: 0.000
Depth of Cut: 0.000
Left Cutter Head
Thickness: 0.000
Depth of Cut: 0.000
Top Cutter Head
Width: 4.500
Depth of Cut: 0.970
Bottom Cutter Head
Width: 4.500
Depth of Cut: 0.125
Grades of Steel
Price Per Cutter Head - Includes Template & Two Knives
V2+RW
chrome coated 72rc face, best seller
great tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
Black Nitride
black nitride case hardened 72rc
medium size runs
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
Endurance
chrome and diamond coated
longest tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
